2.00mm² Red & Black 17.50A Auto Twin Flat PVC Cable | Re: 0-953-00

2.00mm² Red & Black 17.50A Auto Twin Flat PVC Cable | Re: 0-953-00
2.00mm² Red & Black 17.50A Auto Twin Flat PVC Cable | Re: 0-953-00
2.00mm² Red & Black 17.50A Auto Twin Flat PVC Cable | Re: 0-953-00
£38.77 Excl. VAT
RRP £45.42 Excl. VAT
(£46.52 Inc. VAT)
Initial Savings
£6.65
Earn 38 Loyalty Points

Available
Model
0-953-00F
Bar Code
5056119168808
Part Number
0-953-00F
Brand
Durite
Colour
Red/Black
Voltage
12V/24V DC
Amperage
17.5A
Material
Copper/PVC
Ship Weight
2.16 kg


 Durite 17.5A Black and Red standard twin-core automotive cables in a flat moulded sheath for a vehicle wiring loom. PVC sheathed and copper-cored electrical wire supplied on cardboard cable reels for van or workshop storage racks and dispensers.

  • 2mm² (14AWG) Black and Red.
  • 17.5 Amps twin-core automotive cables and vehicle wiring.
  • 28 copper strands at 0.30mm.
  • Outside measurement: 7.9mm x 4.8mm.
  • Manufactured to BS6862-1:1971.
  • Reel length: 10m and 30m.

About the 0-953-00 2.00mm² Black and Red PVC Electric Cables

 Arc Components Limited presents the 0-953-00 and 3-953-00 Durite's light-duty 17.5A Black Negative (-) and Red Positive (+) twin-core automotive cables, ideal for your vehicle's connection to electrical equipment with a low load requirement.
 This high-quality PVC flat sheathed, copper-cored electrical wire is supplied on a 10m or 30m cardboard reel, perfect for storage in your van or workshop ready-use wiring racks. It is 2.0mm² (14 AWG) and features two 28 strands of 0.30mm separate copper wires bound together in a PVC sleeve and then moulded into a flat PVC sheath, with an outside measurement of 7.9mm x 4.8mm. It meets all necessary standards for electrical equipment wiring for domestic and commercial vehicles, including BS6862-1:1971. It has good overall resistance to petrol, diesel and lubricating oils. It is suitable for continuous current loads to a maximum of 17.5 Amps per cable.

 The Durite 0-953-00 and 3-953-00 twin cables are commonly used as conductor wires on low-amperage 12V-24V electrical equipment.

Specifications

Type Twin-core standard automotive wiring
Current Rating 17.5 Amps
Insulation Colour Red and Black
Wire 28/0.30mm copper
Cross-section 2.00mm² (14 AWG)
Voltage For 12 and 24 Volts DC systems (100 Volts DC Max.)
Resistance 9.4mΩ/m at 20℃
Insulation Hard-grade PVC offers good resistance to abrasion and cut-through.
Overall Outside Measurement   7.90mm x 4.80mm
Temperature Minus 30 to +70℃
Length of Cable 30, 100 and 500 Metres
Approvals BS 6862-1:1971
Weight 2.3Kg/7.8Kg
