1.00mm² Red & Black 8.75A Auto Twin Flat PVC Cable | Re: 0-952-51

1.00mm² Red & Black 8.75A Auto Twin Flat PVC Cable | Re: 0-952-51
1.00mm² Red & Black 8.75A Auto Twin Flat PVC Cable | Re: 0-952-51
1.00mm² Red & Black 8.75A Auto Twin Flat PVC Cable | Re: 0-952-51
£25.61 Excl. VAT
RRP £29.10 Excl. VAT
Initial Savings
£3.49
(£30.73 Inc. VAT)
Earn 25 Loyalty Points

Available
Model
0-952-51F
Bar Code
5056119168792
Part Number
0-952-51F
Brand
Durite
Colour
Red/Black
Voltage
12V/24V DC
Amperage
8.75A
Material
Copper/PVC
Weight
1.42 kg


 Durite 8.75A Black and Red standard twin-core automotive cables in a flat moulded sheath for a vehicle wiring loom. PVC sheathed and copper-cored electrical wire supplied on cardboard cable reels for van or workshop storage racks and dispensers.

  • 1mm² (17AWG) Black and Red.
  • 8.75 Amps twin-core automotive cables and vehicle wiring.
  • 14 copper strands at 0.30mm.
  • Outside measurement: 6.5mm x 4.0mm.
  • Manufactured to BS6862-1:1971.
  • Roll length: 30m or 100m.

About the 0-952-51 1.00mm² Black and Red PVC Electric Cables

 Arc Components Limited presents the 0-952-51 and 3-952-51, Durite's light-duty 8.75A Black Negative (-) and Red Positive (+) twin-core automotive cables, ideal for your vehicle's connection to electrical equipment with a low load requirement.
 This high-quality PVC flat sheathed, copper-cored electrical wire is supplied on a 30m or 100m cardboard reel, perfect for storage in your van or workshop ready-use wiring racks. It is 1.0mm² (17 AWG) and features two 14 strands of 0.30mm separate copper wires bound together in a PVC sleeve and then moulded into a flat PVC sheath, with an outside measurement of 6.5mm x 4mm. It meets all necessary standards for electrical equipment wiring for domestic and commercial vehicles, including BS6862-1:1971. It has good overall resistance to petrol, diesel and lubricating oils. It is suitable for continuous current loads to a maximum of 8.75 Amps per cable.

 The Durite 0-952-51 and 3-952-51 twin cables are commonly used as conductor wires on low-amperage 12V-24V electrical equipment.

Specifications

Type Twin-core standard automotive wiring
Current Rating 8.75 Amps
Insulation Colour Red and Black
Wire 14/0.30mm copper
Cross-section 1.00mm² (17 AWG)
Voltage For 12 and 24 Volts DC systems (100 Volts DC Max.)
Resistance 18.9mΩ/m at 20℃
Insulation Hard-grade PVC offers good resistance to abrasion and cut-through.
Overall Outside Measurement   6.5mm x 4.00mm
Temperature Minus 30 to +70℃
Length of Cable 30 and 100 Metre roll options
Approvals BS 6862-1:1971
Weight 1.59Kg/5.2Kg
