RU280B-5176P Albright Single-acting 36-48V 350A Contactor - Intermittent

£63.42  Excl. VAT
  (£76.10 Inc. VAT)
 Excl. VAT

Earn 63 Loyalty Points
Pre-order
Despatch: 9 to 12 Weeks

Weight:  760 g


Model:  RU280B-5176P
Bar Code:  DNA
Part Number:  RU280B-5176P
Brand:  Albright
Colour:  Black
Voltage:  36-48V DC
Amperage:  350A
Material:  Copper/Silver/Bakelite/Steel
Coil type:  Intermittent

Pre-order and back-ordering is available with a current 9 to 12 weeks despatch. Telephone: +44 (0) 1924 823119 or Email us to discuss further requirements.


 Albright RU280B-5176P single-acting 36-48Vdc 350 Amps solenoid contactor, intermittent.

  • The Reduced Silver series are suitable for applications where infrequent switching is specified. In such applications the degradation of the tip is minimal and therefore a higher volume of silver is unnecessary. Developed for Uninterrupted current applications the RU280 is typically used in line contactors or Power Distribution Systems.
  • Due to the configuration of this contactor no repair/contact kit is available.
  • No bracket fitted.
  • All holes on the bottom cover are knocked out.
  • The Contactor is not sealed - Does not meat IP66.

About Intermittent (Int.) RU280 Solenoids

 Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods.

 The contactors have double breaking main contacts with silver alloy tips, which are weld resistant, hardwearing and have excellent conductivity. They are easy to install, with M5 tapped holes in the switch frame together with a range of mounting brackets. Mounting can be vertical or horizontal, when vertical the M10 contact studs should point upwards.

Interrupted Current: The opening and closing on load with frequent switching (resulting in increased contact resistance).
Uninterrupted Current: No or infrequent load switching requirements (maintains a lower contact resistance).

Specifications

Device Type SPST NO
Voltage 36-48V D.C.
Coil Type Intermittent
Amps 350 amp
Coil Resistance (Ohms) 21
Pull-In Voltage (V) 28.0 Maximum
Drop Out Voltage (V) 12.0 Maximum
Coil Power Dissipation (W) 41.81 (36V)/74.32 (48V)
Typical Pull-In Time 30ms
Typical Voltage Drop Per Pole
Across New Contacts At 100A
40mV
Operating Ambient Temperature -40 to +60℃
Weight 755g
Application Uninterrupted
Thermal Current Rating 350A
Intermittent Current Rating:
30% Duty 640A
40% Duty 555A
50% Duty 495A
60% Duty 450A
70% Duty 420A
