0-379-47 Grey Female PAL Type Automotive Fuse 75A

£4.45  Excl. VAT
  (£5.34 Inc. VAT)
RRP:  £5.00  Excl. VAT
Initial Savings:  £0.55
Earn 4 Loyalty Points
Available


Weight:  10 g





Model:  0-379-47
Bar Code:  5056119111101
Part Number:  0-379-47
Brand:  Durite
Colour:  Grey
Voltage:  12V/24V DC
Amperage:  75A


 Durite grey 75 Amps PAL type automotive cartridge fuse.

  • Colour Coded: Grey.
  • Voltage Rating: 32Vdc Maximum.
  • Continuous Rating: 75A.
  • Blow Rating: 150A.
  • Pack Quantity: 1 piece.

Body Dimensions Excluding Clip

  • Width: 19mm.
  • Depth: 14mm.
  • Height: 37mm.

About The Grey 75A Plug-in Cartridge Fuse

 Durite replacement grey 75 Amps plug-in fuses are for vehicle fuseboxes and panels and are used to replace a blown fuse position or to add to a vehicles breakdown kit.

 The ratings for 75A continuous use is based on a circuit constant load being always-on, the 150A blow rating is based on the circuit load being intermittent.

Fuse Ratings

 Continuous ratings for fuses are based on the fact they should blow at the amperage when the circuit is always-on or plugged in. The blow ratings for fuses are based on the fact that the circuit is intermittent and therefore the fuse is required to heat up before blowing.
