SW180A-1111 Albright 24V Single-acting Solenoid Contactor - Continuous

 Albright SW180A-1111 24Vdc 150 Amps single-acting solenoid contactor with an enclosed top cover and auxiliary microswitch, continuous.

• The SW180 series of contactors has been designed for direct current loads, particularly motors as used on small electric vehicles such as industrial trucks, airport tractors, etc.; they have double-breaking contacts with Silver-alloy contact tips, which are weld resistant, hardwearing and have excellent conductivity.
• The contactors are compact in size and are fully serviceable, with a range of spare parts available.
• This version has an enclosed top cover and no mounting bracket.
• Repair contact kit part number: 2180-42.
• Auxiliary switch (2180-796) fitted.
• Varnished Coil
• "U" shaped AMP coil connectors fitted.

Associated Products

• 2159-47 Top Hat shaped mounting bracket.
• 2180-42 Contact kit.
• 2180-796 Auxiliary Microswitch kit.

About Continuous (CO.) SW180A Solenoids

 Continuous contactors, by design, are predominantly used for drive functions on vehicles. They make and break slower than intermittent solenoids and are recommended for prolonged contact periods.

 The SW180 has been designed for direct current loads, including motors on electric vehicles such as industrial trucks. Developed for both interrupted and uninterrupted loads, the SW180 is suitable for switching Resistive, Capacitive and Inductive loads.

 The SW180 features single-pole, single-throw, double-breaking main contacts with Silver-alloy tips, which are weld-resistant, hardwearing and have excellent conductivity. The SW180 has M8 stud main terminals and 6.3mm spade coil connections. It can be mounted via M5 tapped holes or steel mounting brackets (supplied separately). Mounting can be horizontal or vertical. When vertical, the M8 contact studs should point upwards.

Specifications
