0-388-40 Durite Panel Mount Circuit Breaker 40A
Weight: 50 g
Model: 0-388-40
Bar Code: 5056119111781
Part Number: 0-388-40
Brand: Durite
Colour Black
Voltage 12V/24V DC
Amperage 40A
Material Thermoplastic/Brass/Copper/Steel
Durite 40 Amps panel-mounted thermal bimetallic circuit breaker.
- Rated at 40A for 12V and 24Vdc systems.
- Thermal bimetallic with manual reset.
- For panel hole: 12mm diameter.
- Can use splashproof cover: 0-388-97.
Specifications
| Type | Thermal Bimetallic Circuit Breaker |
| Voltage | 240Vac, 50Vdc |
| Amperage | 40A |
| Protection | Operating area IP40
Terminal area: IP00 |
| Dielectric Strength | Test voltage AC 3,000V |
| Weight | 50g |
