HV500F-128 Albright 60Vdc High Voltage Contactor - PWM Controlled

£128.75 Excl. VAT
(£154.50 Inc. VAT)
Earn 128 Loyalty Points

Pre-order
Despatch: 8 to 10 Weeks
Model
HV500F-128
Bar Code
DNA
Part Number
HV500F-128
Brand
Albright
Colour
Black/Red
Voltage
60V DC
Amperage
250A
Material
Copper/Silver/Bakelite
Coil type
PWM Controlled
Ship Weight
410 g


 Pre-orders and back-ordering are available for all Albright brand out-of-stock items, with a current lead time of approximately 8 to 10 weeks despatch.

  • Ordering more Albright brand products than is shown in stock will put your order into a backorder process.
  • Request "Ship all available" in the order comments section if you order more units than are available.

 Telephone: +44 (0) 1924 823119 or Email us to discuss further requirements.


 Albright International HV500F-128 60Vdc 'Normally Open' solenoid contactor, PWM controlled.

  • 60 Volts DC single-pole, single-throw (SPST) contactor with flying leads.
  • PWM operation is reliant on smooth DC supply.
  • These contactors are primarily for use with Direct Current (DC) or Alternating Current (AC) loads via the main stud terminals. The coils are switched with a Direct Current only.
  • PWM is not compatible with ramped supply voltages.
  • Initial Operating Wattage: 48W
  • Running Wattage: 3W
  • Voltager range of the PWM Board is 45 to 90V DC with a suitable current/power supply.

Applications for Types of HV500 Contactors Include

  • Automotive - Vehicle and Charging
  • Battery Management Systems
  • Power Distribution Units
  • Renewable Energy

Dimensions

  • Height, including terminals and coil base: 71mm.
  • Coil width, including base: 81mm.

About PWM Controlled HV500 Solenoids

 This contactor is fitted with a PWM Coil Economiser - allowing for significantly reduced power consumption while maintaining optimum switching capability.

 Hermetic Sealing: The Albright HV range is fully hermetically sealed, allowing durability in extreme environments or when operating in potentially hazardous conditions. Please note; hermetic sealing also includes the PWM circuit.

 Mounting is through a rotatable bracket which offers six angles for orientation. This allows for complete flexibility with the position of main contacts, allowing for customer ease of connection. Recommended panel mounting tightening torque is 2.5Nm to 3Nm.

Interrupted Current: The opening and closing on load with frequent switching (resulting in increased contact resistance).
Uninterrupted Current: No or infrequent load switching requirements (maintains a lower contact resistance).

Specifications

Device Type NO - SP - ST
Voltage 60Vdc
Coil Type PWM Controlled (Pulse Width Modulation)
Continuous Current 250 Amps
Continuous Current (Max.) 500 Amps
Coil Resistance (Ohms) 75
Pull-In Voltage (V) 45.0 Max.
Drop Out Voltage (V) 24.0 Max.
Coil Power Dissipation (W) 48.0
Environmental Seal Contacts and PWM Circuit Hermetically Sealed - Exceeds IP67
Typical Voltage Drop Per Pole
Across New Contacts At 100A
< 30mV
Insulation Resistance >200MΩ
Maximum Altitude 3000m
Temperature - Operating -40 to +85℃
Temperature - Storage -40 to +120℃
Vibration, Sinusoidal 80 - 2000Hz Peak 20G
Weight 420g
Application Interrupted Uninterrupted
Thermal Current Rating 250A 500A
Intermittent Current Rating:
30% Duty 455A 915A
40% Duty 395A 790A
50% Duty 355A 705A
60% Duty 325A 645A
70% Duty 300A 600A
