0-380-55 5A Tan Mini Blade Fuse Replacement Circuit Breaker

0-380-55 5A Tan Mini Blade Fuse Replacement Circuit Breaker
0-380-55 5A Tan Mini Blade Fuse Replacement Circuit Breaker
0-380-55 5A Tan Mini Blade Fuse Replacement Circuit Breaker
£15.95 Excl. VAT
RRP £18.12 Excl. VAT
Initial Savings
(£19.14 Inc. VAT)
Earn 15 Loyalty Points
Bar Code
Part Number
29V DC Max.
5 g

 Durite tan-coloured 5 Amps MINI blade fuse replacement circuit breaker with manual reset surge protection for automotive vehicles.

  • Colour: Tan.
  • Current Rating: 5A for 12-24VDC systems.
  • Voltage Rating: 32Vdc Maximum.
  • Thermal bimetallic with manual reset.
  • Will replace MINI blade fuses in many fuse holders and boxes.
  • Pack Quantity: 1 Piece.


  • Length: 13.3mm
  • Width: 7.0mm
  • Height: 36.0mm (inc blades and trip extended)

About the 0-380-55 Tan 5 Amps Mini Blade Circuit Breaker

 The 5A Tan coloured thermal circuit breakers from Arc Components Ltd are ideally suited to overload protection of motors, transformers, magnetic valves, on-board electrical systems and low voltage lines. This single pole, thermal miniaturised circuit breaker is designed for automotive applications and fits into fuse blocks designed to ISO 8820-3, Type F. Always check the clearance for closure if a fusebox cover is used.


Type Manual Reset Circuit Breaker
Voltage 12-24 Volts DC (maximum 32 Volts DC)
Voltage drop Less than 150mV
Current ratings 5A
Colour code Tan
Vibration 10g (57-500 Hz)
Degree of protection Operating area IP40, terminal area IP00
Operating temperature Minus 40℃ to +85℃
Humidity 95% RH
Nett Weight 3g
